ESPAÑOL
1
7
2
3
4
5
14
10
11
9
12 13
8
TIPO C (5)
TIPO A (13)
TUERCA
(2)
TORNILLO
(2)
TIPO B (3)
TIRA DE GOMA
BANDA ADHESIVA
PANEL GUÍA
CHAPA DE SOPORTE
PARALA VENTANA
PANEL GUÍA
GUÍA MARCO(2)
SOPORTE DE ALFÉIZAR(2)
6
1. GABINETE
2. DEFLECTOR DE AIRE HORIZONTAL
(REJILLA VERTICAL)
3. DEFLECTOR DE AIRE VERTICAL
(REJILLA HORIZONTAL)
4. DESCARGA DE AIRE
5. REJILLA FRONTAL
6. ENTRADA DE AIRE
(REJILLA PARA ENTRADA)
7. FILTRO DE AIRE
8. PANEL DE CONTROL
9. CABLE DE ALIMENTACION
10. EVAPORADOR
11. CONDENSADOR
12. COMPRESOR
13. PLATO DE BASE
14. RIEL DE MONTAJE SUPERIOR
Instrucciones para la instalación
Características
Conocer el nombre de las partes antes de instalar el aire, lo ayudará a entender mejor el proceso de instalación.
Accesorios de Instalación
10
