ENGLISH
10
1 7 2 3 4 5 14 10 11 9 12 13 8
Type C (5)
Type A (13)
Bolt (2)
Nut (2)
Type B (3)
Foam top
window gasket
Window sash seal
Right frame
curtain
Window locking
bracket
Left frame curtain
Frame guide(2)
Sill support(2)
6
Installation Instructions
Learning part names prior to installation will help you understanding the installation procedure.
1. CABINET
2. HORIZONTAL AIR DEFLECTOR
(VERTICAL LOUVER)
3. VERTICAL AIR DEFLECTOR
(HORIZONTAL LOUVER)
4. AIR DISCHARGE
5. FRONT GRILLE
6. AIR INTAKE(INLET GRILLE)
7. AIR FILTER
8. CONTROL BOARD
9. POWER CORD
10. EVAPORATOR
11. CONDENSER
12. COMPRESSOR
13. BASE PAN
14. TOP MOUNTING RAIL
Features
Installation Hardware
