FS Functions
FS-4 HD and FS-4Pro HD Portable DTE Recorders 51
FS-4 HD System Information Screens
The FS-4 HD automatically creates information screens to
indicate conditions such as high temperature, power
remaining, or drive capacity remaining.
Press
OK
to clear the screen and return to the last screen.
12 Displays an absolute timecode value for the particular
session: the sum of all COUNTER timecodes on
connected volumes.
Absolute is primarily used when setting the FS-4 HD to
AV/C mode and controlling it with an external FireWire
device, such as a computer.
DV (NTSC or PAL) and HD
The information displayed in fields 11 and 12 depends, in part, on which
Recorder Mode is set.
DV RECORDER
Line 11 displays the Standard Digital (SD) video format. It can not be
changed.
HD RECORDER
Line 11 displays the HD resolution of the current track which depends on
the camcorder in use with the FS-4 HD unit. Possible values are:
• 1080/50i TC
• 1080/60i TC
• 720/60 TC
• 720/50 TC
• 720/30p TC
• 720/25p TC
• 720/24p TC
• 576/50p TC
• 480/60p TC
Refer to the camcorder manual for supported resolutions.
WARNING
5%
POWER
REMAINING
OK
