FOCUS Enhancements FOCUS FireStore FS-4 Pro - Manual (Page 28)

Quickstart
12 FS-4 HD and FS-4Pro HD Portable DTE Recorders
Computer FireWire Connector
• In/Out: 6-pin IEEE-1394a port x 1
• Asynchronous Data I/O
Remote Control, Serial Connector
• GPI / RS232C; 3.5mm TRS mini jack. (3.5mm to DB-9
cable accessory available).
• Can configure to act as a simple contact closure or RS-
232C port.
• Connect an optional wired remote commander.
Camera FireWire Connector
• DV/HD Video I/O
• 6-pin IEEE-1394a connector
• Isochronous 25Mb/s DV video I/O
FS-4 HD supports 1080i/720p video I/O when used with
HDV camcorders equipped with a 1394 connection.
• DV Audio: embedded 2-channel (48kHz, 16-bit) or 2-
channel (12-bit, 32kHz) audio, 720p/1080i HDV MPEG1
Audio Layer II.
Status LED States
LED Indicates
Off Power OFF
Green Power ON (Power On but there is no activity.)
Orange, solid Playback
Orange, fluttering Hard drive being accessed during playback.
Red, solid Recording Mode
Red, blinking Recording Pause
4-Channel Audio
4-channel (12-bit, 32kHz) audio is available only with RawDV
format.
