Page 66: Use the
FS Functions
50 FS-4 HD and FS-4Pro HD Portable DTE Recorders
10.
Reel Display
FS-4Pro HD only
In
Record
or
Playback
modes, this item displays the particular
REEL that a clip is located in or, has been marked to. If in
PLAY FROM
>
REEL LIST
mode, the REEL appears in
brackets for example,
REEL has been selected.
11.
DISP
information field that displays data type.
12.
DISP
information field that displays current data.
DISP (display) Information Fields
Use the
DISP
function button to display current operation
information fields 11 and 12. The data shown depends on
the mode of operation, i.e. DV or HD Recorder.
Pressing the
DISP
button advances the display to the next
category of information. Below is a table of the data types
and data available with
DISP
.
Field
Number
Data Type /
Data Description
11
COUNTER
12
Shows frame count of current video clip during record or
playback.
11
REMAINING
12
Record
: counts down number of available frames
remaining, as time, on a specific disk.
Playback
: displays time remaining of the current clip.
11
DV (NTSC or PAL) or HD (see note following table)
12
Record
: displays the external timecode value being
generated by a camcorder or other device during a
recording session. Timecode mode must be set to
EXT
TC
for this function to operate, refer to
Playback
: displays the embedded DV timecode value in
a particular track.
11
UB NTSC
12
Displays the set user bit value in a particular clip. A user
bit value must be added for this to display, refer to
11
ABSOLUTE
