Operating the Meter Using the Computer Interface
Computer Interface Command Set
5
5-21
Table 5-10. IEEE-488 Common Commands (cont)
Command Name Description
Sets the "Service Request Enable Register" to , an
integer between 0 and 255. The value of bit six is ignored
because it is not used by the Service Request Enable
Register.
is an integer whose binary equivalent corresponds to
the state (1 or 0) of bits in the register. If is not
between 0 and 255, an Execution Error is generated.
Meter returns the of the "Service Request Enable
Register" (with bit six set to zero) is an integer whose
binary equivalent corresponds to the state (1 or 0) of bits in
the register.
Meter returns the of the "Status Byte" with bit six as
the "Master Summary" bit.
is an integer whose binary equivalent corresponds to
the state (1 or 0) of bits in the register.
Causes the meter to trigger a measurement when parsed.
Causes the meter to run internal self-test. Test takes about
15 seconds. All display segments are lit during the test. No
user interaction is required.
The number returned corresponds to a state described in the
table below. Meter reverts to power-up configuration after
tests performed.
Number State
*SRE
*SRE?
*STB?*TRG
*TST
Service Request
Enable
Service Request
Enable Query
Read Status Byte
Trigger
Self-Test Query
0
1
2
4
8
16
32
64
128
256
Passes
A/ D self-test failed
A/D dead
EEPROM instrument configuration bad
EEPROM calibration data bad
Display dead
Display self-test failed
ROM test failed
External RAM test failed
Internal RAM test failed
*WAI Wait-to-continue
EXAMPLE: Decimal 9 (8 plus 1) converts to binary
000010010, meaning the A/D self-test failed and EEPROM
calibration data are bad.
Command required by IEEE-488.2 standard. Non-operational
in Fluke 45 Dual Display Multimeter. Command accepted but
has no effect.
