Accuracy

Accuracy

Range

Frequency

Slow

Medium

Fast

mA (To 100 mA)

mA (To 100 mA)

mA (To 100 mA)

A (1-10A)

A (1-10A)

A (0.5 to 1A)

A (0.5 to 1A)

20-50 Hz

50 Hz-10 kHz

10 -20 kHz

20-50 Hz

50 Hz-2 kHz

20-50 Hz

50Hz-2 kHz

2 % + 100

0.5 % + 100

2 % + 200

2 % + 100

1 % + 100

2 % + 300

1 % + 300

2 % + 10

0.5 % + 10

2 % + 20

2 % + 10

1 % + 10

2 % + 30

1 % + 30

7 % + 2

0.8 % + 2

2 % + 3

7 % + 2

1.3 % + 2

7 % + 4

1.3 % + 4

mA accuracy specifications apply within the following limits, based on reading rate:

Slow Reading Rate:

Between 15,000 and 99,999 counts (full range)

Medium Reading Rate:

Between 1,500 and 30,000 counts (full range)

Fast Reading Rate:

Between 150 and 3,000 counts (full range)

Maximum Crest Factor

3.0

Maximum Input

To be used in protected, low energy circuits only, not to exceed 250 V or 4800
Volt-Amps. (IEC 664 Installation Category II.)

mA

300 mA dc or ac rms. Protected with a 500 mA, 250 V, IEC 127-sheet 1, fast
blow fuse

A

10 A dc or ac rms continuous, or 20 A dc or ac rms for 30 seconds maximum.
Protected with a 15 A, 250 V, 10,000 A interrupt rating, fast blow fuse.

Note

Resistance between the COM binding post and the meter’s internal
measuring circuits is approximately .003

.
