Operating the Meter From the Front Panel
Selecting A Function Modifier
3
3-15
Table 3-10.
S
Button Operations
Pushbuttons Operations
S
then
Z
Show volts ac reading in secondary display
S
then
Y
Show volts dc reading in secondary display
S
then
D
Show amperes ac reading in secondary display
S
then
C
Show amperes dc reading in secondary display
S
then
O
Show ohms reading in secondary display
S
then
F
Show Hz reading in secondary display
S
then
G
Show diode test reading in secondary display
S
then
E
(COMP)
Compare mode in primary display. (See "Using the Compare Function” in Chapter
3, below.)
S
then
T
(LO)
Edit Compare mode low point. (See "Using the Compare Function" in Chapter 3,
below.)
S
then
U
(Hi)
Edit Compare mode high point. (See "USING THE COMPARE FUNCTION” in
Chapter 3, below)
S
and
T
(LO)
Store value on primary display as LO compare point (See "USING THE
COMPARE FUNCTION" in Chapter 3, below.)
S
and U
(Hl)
Store value on primary display as Hl compare point (See "USING THE COMPARE
FUNCTION" in Chapter 3, below.)
S
then
K
(REF # )
Edit relative base. (See "Using the List and Number Editor" in Chapter 3 below.)
S
and
K
Toggle display of relative base in secondary display.
S
then
H
(THRESH)
Select Touch Hold sensitivity threshold
S
then
I
(REF e )
Select dB reference impedance.
S
then
J
(ADDR)
Select computer interface address for IEEE-488 operations or RS-232 print only
rate. (See also "RS-232 Print-Only Mode" in Chapter 5.)
S
then
R
(BAUD)
Select RS-232 baud rate or "IEEE" to enable an installed IEEE-488 interface.
S
Then
S
Turn off secondary display, leaving primary display unaffected.
S
and
E
Store present operating configuration of meter as power-up configuration. (See
"Changing the Power-Up Configuration" later in Chapter 3.)
S
and
R
Display software version.
