FUJITSU MPA3043AT User Manual
Page 91
C141-E034-02EN
5 - 30
Table 5.4
Information to be read by IDENTIFY DEVICE command (1 of 3)
Word
Value
Description
0
X‘0C5A’
General Configuration *1
1
X‘0D3E’
X‘13DE’
X‘1A7C’
X‘2352’
X‘2A62’
Number of cylinders
MPA3017AT: X‘0D3E’
MPA3026AT: X‘13DE’
MPA3035AT: X‘1A7C’
MPA3043AT: X‘2352’
MPA3052AT: X‘2A62’
2
X‘0000’
Reserved
3
X‘0010’ or
X‘000F’
Number of Heads
MPA3017AT: X‘0010’
MPA3026AT: X‘0010’
MPA3035AT: X‘0010’
MPA3043AT: X‘000F’
MPA3052AT: X‘000F’
4
X‘0000’
Undefined
5
X‘0000’
Undefined
6
X‘003F’
Number of sectors per track
7-9
X‘000000000000’
Undefined
10-19
–
Serial number (ASCII code) *2
20-21
X‘00000000’
Vendor specific
22
X‘0004’
Number of ECC bytes transferred at READ LONG or WRITE LONG command
23-26
–
Firmware revision (ASCII code) *3
27-46
–
Model number (ASCII code) *4
47
X‘8020’
Maximum number of sectors per interrupt on READ/WRITE MULTIPLE command
48
X‘0000’
Reserved
49
X‘0B00’
Capabilities *5
50
X‘0000’
Reserved
51
X‘0200’
PIO data transfer mode *6
52
X‘0000’
Reserved
53
X‘0003’ or
X‘0007’
Enable/disable setting of words 54-58, 64-70 and 88 *7
54
(Variable)
umber of current Cylinders
55
(Variable)
Number of current Head
56
(Variable)
Number of current sectors per track
57-58
(Variable)
Total number of current sectors
59
*8
Transfer sector count currently set by READ/WRITE MULTIPLE command
60-61
X‘00342778’
X‘004E3B34’
X‘00684EF0’
X‘008262AC’
X‘009C7668’
Total number of user addressable sectors (LBA mode only)
MPA3017AT: X‘00342778’
MPA3026AT: X‘004E3B34’
MPA3035AT: X‘00684EF0’
MPA3043AT: X‘008262AC’
MPA3052AT: X‘009C7668’
62
X‘0000’
Reserved
63
X‘xx07’
Multiword DMA transfer mode *9
64
X‘0003’
Advance PIO transfer mode support status *10
65
X‘0078’
Minimum multiword DMA transfer cycle time per word : 120 [ns]
66
X‘0078’
Manufacturer's recommended DMA transfer cycle time : 120 [ns]
67
X‘00F0’
Minimum PIO transfer cycle time without flow control : 240 [ns]
68
X‘0078’
Minimum PIO transfer cycle time with IORDY flow control : 120 [ns]
69-79
X‘00’
Reserved
80
X‘000E’
Major version number *11
81
X‘0000’
Minor version number (not reported)
82
X‘0009’
Support of command sets *12
83
X‘4000’
Support of command sets (fixed)
84-87
X‘00’
Reserved
88
X‘0000’ or
X‘0X07’
Ultra DMA modes *13
