C141-E034-02EN 3 - 8
3.3.2 Cable connector specifications
Table 3.2 lists the recommended specifications for the cable connectors.
Table 3.2 Cable connector specifications
Name Model Manufacturer
Cable socket
(closed-end type)
FCN-707B040-AU/B Fujitsu
Cable socket
(through-end type)
FCN-707B040-AU/O Fujitsu
Signal cable 445-248-40 SPECTERS STRIP
Cable socket housing 1-480424-0 AMP
Contact 60617-4 AMP
Signal cable AWG 18 to 24
Note :
The cable of twisted pairs and neighboring line separated individually is not allowed to use for
the host interface cable. It is because that the location of signal lines in these cables is not
fixed, and so the problem on the crosstalk among signal lines may occur.
3.3.3 Device connection
Figure 3.8 shows how to connect the devices.
ATA interface cable Power supply cable
DC
power supply
Disk Drive #1
Disk Drive #0
Host system
Figure 3.8 Cable connections
Power supply cable
(CN1)
ATA interface cable
(40-pin, CN1)
