MIDI In/Out Data Format
VM200 User’s Guide 223
4. Bulk Dump (& Request)
Bulk Dump is received when [BLK DMP EQ.] is set to ON and when [RX CH] and DEVICE No.
match.
The received Bulk Dump is immediately written into the specified memory.
When the VM200 receives the Bulk Dump Request, it immediately transmits Bulk Dump.
Bulk Dump is transmitted on the channel specified by [TX CH] when you operate the key in the
[BULK DUMP] page.
In response to Bulk Dump Request, Bulk Dump is sent on the channel specified by [RX CH].
4-1.Bulk Dump Request
<< Setup Bulk Dump Request >>
f0 51 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 01 f7
01:System, 02:Midi, 03:Locate, 127:All Setup
<< Scene Memory Bulk Dump Request >>
f0 51 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 02 f7
0: Edit Buffer, 1 – 100: UserMemory, 127: All User Memory
<< Eff Library Bulk Dump Request >>
f0 51 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 03 f7
50 – 99: User Library, 127: All User Library
<< Eq Library Bulk Dump Request >>
f0 51 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 04 f7
50 – 99: User Library, 127: All User Library
<< PGM Table Bulk Dump Request >>
f0 51 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 05 00 f7
<< CTL Table Bulk Dump Request >>
f0 51 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 06 00 f7
4-2.BULK DUMP OUT FORMAT
<< Setup Bulk Dump Format >>
f0 51 3B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 01
--- f7
<< Scene Memory Bulk Dump Format >>
f0 51 3B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 02 >
--- f7
0: Edit Buffer, 1 – 100: UserMemory
<< Eff Library Bulk Dump Format >>
f0 51 3B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 03 >
--- f7
50 – 99: User Library
<< Eq Library Bulk Dump Format >>
f0 51 3B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 04 >
--- f7
50 – 99: User Library
<< PGM Table Bulk Dump Format >>
f0 51 3B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 05 00
--- f7
<< CTL Table Bulk Dump Format >>
f0 51 3B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 06 00
--- f7
* “Byte Count” is the number of bytes counted from the byte following up to the
byte before .
* “Check Sum” covers after before , with all EOR being removed.
