216 VM200 User’s Guide
MIDI In/Out Data
Format
1. CHANGE MESSAGE
1-1.NOTE OFF (8n)
NOTE OFF messages are not received or
transmitted.
1-2.NOTE ON (9n)
NOTE ON messages are not received or
transmitted.
1-3.CONTROL CHANGE (Bn)
Control Change messages are received only
when [CONTROL CHANGE RX] is set to ON
and the receive channel [RX CH] matches. If
[RX CH] is set to OMNI, the message is
received regardless of which channel is receiv-
ing.
Control Change messages are “echoed” when
[ECHO] is set to ON.
The parameters are controlled based on the
settings selected by [CONTROL CHANGE
TABLE].
If the messages are received while the [CTL
TABLE] setting page is displayed, the cursor
automatically moves to the corresponding
Control Change number.
Control Change messages are transmitted on
the channel set by [TX CH] when you operate
the or item assigned in the table selected by
[CONTROL CHANGE TABLE] and when
[CONTROL CHANGE TX] is set to ON.
If the same item is assigned to multiple Con-
trol numbers, the smallest Control number
will be transmitted.
STATUS 1011nnnn Bn Control Change
DATA 0cccccccc cc Control No. (0–95, 102–119)
9vvvvvvvv vv Control Value (0–127)
1-4.PROGRAM CHANGE (Bn)
Program Change messages are received only
when [PROGRAM CHANGE RX] is set to ON
and the receive channel [RX CH] matches. If
[RX CH] is set to OMNI, the message is
received regardless of which channel is receiv-
ing.
Program Change messages are “echoed” when
[ECHO] is set to ON.
A scene is recalled according to the settings
selected by [PROGRAM CHANGE TABLE].
If the messages are received while the [PGM
TABLE] setting page is displayed, the cursor
automatically moves to the corresponding
PGM number.
Program Change messages are transmitted on
the channel set by [TX CH] when you recall a
scene assigned in the table selected by [PRO-
GRAM CHANGE TABLE] and when [PRO-
GRAM CHANGE TX] is set to ON.
If the same scene is assigned to multiple Pro-
gram numbers, the smallest Program number
will be transmitted.
STATUS 1100nnnn Cn Program Change
DATA 0nnnnnnn nn Program No. (0–127)
2. EXCLUSIVE MESSAGE (F0–F7)
2-1.MOTION CONTROL STATE (MCS
MMC STOP/PLAY/FOR-
WARD/REWIND/
RECORD/PAUSE
Operating the key in the [MMC SEND] page
will transmit these messages.
Use [Dev ID.] to specify the destination.
STATUS 11110000 F0 System Exclusive Message
ID No. 01111111 7F Real Time System Exclusive
Device ID0ddddddd dd Destination (00–7E, 7F:all call)
Command 00000110 06 MMC sub-id
0ccccccc cc Command String
[1]: Stop
[2]: Play
[4]: Fast Forward
[5]: Rewind
[6]: Record Strobe
[9]: Pause
EOX 11110111 F7 End Of Exclusive
2-2.MOTION CONTROL PROCESS (MCP)
MMC LOCATE (target)
Operating the key in the [MMC SEND] page
will transmit these messages.
Use [Dev ID] to specify the destination.
STATUS 11110000 F0 System Exclusive Message
ID No. 01111111 7F Real Time System Exclusive
Device ID0ddddddd dd Destination (00–7E, 7F:all call)
Command 00000110 06 MMC sub-id
01000100 44 Locate
00000110 06 byte count
00000001 01 “target” sub command
0hhhhhhh hh hour
0mmmmmmm mm minute
0ssssss ss second
0fffffff ff frame
0sssssss ss sub frame (only ‘0’)
EOX 11110111 F7 End Of Exclusive
