222 VM200 User’s Guide
<< CH1-20 – Eq Lib Store >>
command: f0 51 19 10 5f
f7
1-16:Ch 0x7f:All
50-99:Eq lib number.
Max 9byte lib Name ascii string.
<< CH1-20 – Ch Pair >>
command: f0 51 19 10 70 f7
request: f0 51 29 10 70 f7
status: f0 51 39 10 70 f7
1-20:Ch 0x7f:all_Ch
0:off 1:on
<< CH1-20 – Fader Group >>
command: f0 51 19 10 71 f7
request: f0 51 29 10 71 f7
status: f0 51 39 10 71 f7
1-20:Ch 0x7f:all_Ch
0:off 1:A 2:B 3:C
<< CH1-20 – Mute Group >>
command: f0 51 19 10 72 f7
request: f0 51 29 10 72 f7
status: f0 51 39 10 72 f7
1-20:Ch 0x7f:all_Ch
0:off 1:A 2:B 3:C
<< CH1-20 – Ch Solo Safe >>
command: f0 51 19 10 73 f7
request: f0 51 29 10 73 f7
status: f0 51 39 10 73 f7
1-20:Ch 0x7f:all_Ch
0:off 1:on
<< CH1-20 – Ch Recall Safe >>
command: f0 51 19 10 74 f7
request: f0 51 29 10 74 f7
status: f0 51 39 10 74 f7
1-20:Ch 0x7f:all_Ch
0:off 1:on
Effects Commands
<< Eff Type >>
command: f0 51 1a 10 f7
request: f0 51 2a 10 f7
command f0 51 3a 10 f7
1:eff1 2:eff2 0x7f:all_Ch
0 to (EFFTYP_END - 1)
<< Eff Parameter >>
command: f0 51 1a 11
f7
request: f0 51 2a 11 f7
command: f0 51 3a 11 f7
1:eff1 2:eff2 0x7f:all_Ch
1 to 12 or 0x7f:all_params.
+ : 14bit parameter value.
<< Eff Name >>
command: f0 51 1a 70 f7
request: f0 51 2a 70 f7
status: f0 51 3a 70 f7
1:eff1 2:eff2 0x7f:all_eff
Max 9byte lib Name ascii string.
<< Eff Lib Recall >>
command: f0 51 1a 72 f7
1:eff1 2:eff2 0x7f:all_eff
0 to 99 eff lib number.
<< Eff Lib Store >>
command: f0 51 1a 73 f7
1:eff1 2:eff2
50 to 99 eff lib number.
Remote Commands
<< Key Remote >>
command: f0 51 1f 01 f7
01-08:[Channel]On, 09:[Master]On,
11-18:[Channel]Solo, 19:[Master]Solo
1a:[Rec Buss]Solo, 21-28:[Channel]EQ Edit
31:[Fader Mode]Channel,
32-35:[Fader Mode]Aux1-4,
36-37:[Fader Mode]Eff1-2
38:[Key Mode]Routing/Phase
39:[Key Mode]Pair/Group
3a:[Key Mode]Ch View
3b:[Key Mode]Channel/Meter
41:[Current Scene Status], 42:[Setup]System
43:[Setup]Midi, 51:[Page Sel]1-8
52:[Page Sel]9-16, 53:[Page Sel]17-20
61:[Selected EQ]EQ On
62:[Selected EQ] Library Recall
63:[Selected EQ]Library Store
64:[Eff Edit]Eff1, 65:[Eff Edit]Eff2
66:[Eff Edit]Library Recall
67:[Eff Edit]Library Store
68:[Scene Memory]Recall
69:[Scene Memory]Store
71:<-/-1, 72:+1->, 73:Exit, 74:Enter
0:off 1:on
<< Key Remote >>
command: f0 51 1f 02 f7
01-12:Encoder (top raw from left:1-4,
bottom raw from left: 9-12), 11:Data
0-3f:-64 – -1, 40-7f:+1 – +64
0–3f:variation=0x40-Val
40–7f:variation=Val-0x3f
