3. SYSTEM MENU
3-2
3.2 SYSTEM SETTING Menu
The SYSTEM SETTING menu mainly sets picture layout options.
DISP ALM TX/RX E/S SYSTEM
Select picture scrolling direction.
[-/+]: Change set, [EXIT]: Exit
SYSTEM SETTING
PICT ADV DIR : LEFT
DISP DIVISION :
DEPTH SCALE : RIGHT
DEPTH UNIT
: ft
FREE SHIFT : OFF
AUTO SHIFT : OFF
ZOOM MODE : BOTTOM LOCK
LANGUAGE : ENGLISH
SYSTEM SETTING menu
PICT ADV DIR
Chooses picture advance direction: right or left which advances the picture in
both right and left directions from the screen center.
DISP DIVISION
Sets display division for the dual frequency picture. , vertical; , horizontal.
DEPTH SCALE
Chooses where to position the depth scale; right, center or off.
DEPTH UNIT
Chooses unit of depth measurement; meters, feet, fathoms, hiro (Japanese),
passi/braza. Note that the Japanese characters for hiro appear when using hiro.
FREE SHIFT
Sets shift value independently for each range (ON) or commonly for all ranges
(OFF).
