E-44
• Specifications and external appearance may be change for the sake of improvement.
• is a worldwide trademark of Fujitsu General Limited and is a registered trademark in Japan, the U.S.A. and other countries or areas.
Model P42VHA20W/P42VHA20A P42VHA20U
Screen size 42" wide screen:
92.0 cm (W) x 51.8 cm (H) (106.0 cm diagonal)
36.2 inch (W) x 20.4 inch (H) (41.7 inch diagonal)
Aspect ratio 16:9 (wide)
Weight 29.5 kg / 65.0 lbs
Outer dimensions 103.7 (W) x 64.2 (H) x 8.5 (D) cm
40.8 (W) x 25.3 (H) x 3.3 (D) inch
Power supply 220–240 VAC 50/60 Hz 120 VAC 50/60 Hz
Current rating 1.8–1.5 A 4.3 A
Number of pixels 852 (H) x 480 (V)
Display modes Video, S-video input: Normal/Auto/Wide1/Wide2/Zoom1/Zoom2
Component video input: Normal/Wide1/Wide2/Zoom1/Zoom2
RGB: Normal/Wide/Zoom
Colors 16.77 million
External equipment terminals
Video input terminals VIDEO1 INPUT (Video input) 1 RCA terminal 1 Vp-p/75
Ω
VIDEO2 INPUT(S-video input) 1 S terminal Y: 1 Vp-p/75
Ω
C: 0.286 Vp-p/75
Ω
VIDEO3/VIDEO4 INPUT 3 RCA terminals Y: 1 Vp-p/75
Ω
(Component video input) P B /C B : 0.7 Vp-p/75
Ω
P R /C R : 0.7 Vp-p/75
Ω
Applicable systems NTSC/PAL/SECAM/PAL60/N-PAL/M-PAL/4.43NTSC
PC input terminal RGB1 input 1 DVI-D terminal (EIA/CEA-861 Compliant)
RGB2 input mD-sub, 3 rows, 15-pin
Picture signal: 0.7 Vp-p/75
Ω
Synchronization signal:TTL level
Sound terminals 2 sound input pin jacks (L/R) (3 lines)
500 mVrms/at least 22 k
Ω
Control terminal 1 RS-232C connector (D-sub 9-pin)
External speaker output terminal Effective max. output: 12 W + 12 W (EIAJ), 6
Ω
Operating conditions Temperature: 0 to 40 °C / 32 to 104 °F
Humidity:
20 to 80 %
Accessories 1 remote control, 2AA batteries, 1 instruction manual, 1 power cable, 2 big ferrite cores,
2 small ferrite cores
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
Regulation --- P42VHA20W/P42VHA20A
• UL, CSA Safety: UL6500, C-UL
EMC: FCC Part 15 Class B, ICES-003 Class B
• CE Safety: EN60065
EMC: EN55022 1998, Class B
EN61000-3-2 1995
EN61000-3-3 1995
EN55024
1998
EN61000-4-2 1995
EN61000-4-3 1996
EN61000-4-4 1995
EN61000-4-5 1995
EN61000-4-6 1996
EN61000-4-8 1993
EN61000-4-11 1994
• AS Safety: IEC60065
EMC: AS/NZS 3548
Regulation --- P42VHA20U
• UL, CSA Safety: UL6500, C-UL
EMC: FCC Part 15 Class B, ICES-003 Class B
• CE Safety: EN60065
EMC: EN55022 1998, Class B
EN61000-3-2 1995
EN61000-3-3 1995
EN55024
1998
EN61000-4-2 1995
EN61000-4-3 1996
EN61000-4-4 1995
EN61000-4-5 1995
EN61000-4-6 1996
EN61000-4-8 1993
EN61000-4-11 1994
• AS Safety: IEC60065
EMC: AS/NZS 3548
SPECIFICATION (Continued)
