Page 17
English
E-17
PC
• As the cable for connecting a PC differs with the PC model, please consult your dealer for information on the right cable to purchase.
• The PC can be connected to either the front side or the rear side, whichever is most convenient.
To RGB output (mD-sub)
To audio output
To RGB output (DVI-D)
To RGB1 input
(DVI-D)
To audio
input
To RGB2
input
(mD-sub)
Note
• Unplug the power cord from the AC outlet before you connect external components.
• Also refer to the instructions for the component to be connected.
• When inputting audio, connect to the terminals corresponding to the used video input or RGB input.
Bottom of Display (Ex.: P42VHA10)
