28
Model DS-80
Unit DISTRIBUTOR DS-801
ELECTRICAL PARTS LIST Ref.Dwg. C7247-K03-A
2000-01 Block No.
SYMBOL TYPE CODE No. REMARKS SHIPPABLE
ASSEMBLY
PRINTED CIRCUIT BOARD
65P6010,JPW
002-889-490
X
ASSEMBLY
DS-801
002-889-470 POWER SUPPLY X
POWER SUPPLY ASSEMBLY
DS-801-100
002-889-410
X
DS-801-110 002-889-420 X
DS-801-115 002-889-430 X
DS-801-200 002-889-440 X
DS-801-220 002-889-450 X
DS-801-230 002-889-460 X
SWITCH
S1 S-331 000-474-214
VARISTOR
CR1 ERZV-20D471 000-136-287
TERMINAL BOARD
TB101 F1003-20A-2P 000-142-631
FUSE HOLDER
F1 FH-001AF 000-138-909
POWER SUPPLY
PD1 FAW-24-2R1 000-142-633
NOISE FILTER
XF1 ZAC2210-11 000-120-155
