1.5 Main Menu Operation
Functions of the DS-80 are selected
through the menu.
1. Press the [MENU] key to open the
menu.
MENU
DISTANCE RUN DISPLAY
DEMO
SYSTEM MENU
SYSTEM MENU2
2. Press the Omnipad at or to select
a menu item (current selection is
highlighted) and press the [ENT] key.
For example, when DISTANCE RUN
DISPLAY is selected the following
display appears. Distance run is a form
of contact closure, 200 pulses/nm. To
select IEC 61162 sentence, see
paragraph 1.6.1.
DISTANCE RUN DISPLAY
DATA DISPLAY
CONTACT CLOSURE
RESET OFF
SET
0.00nm
ENT SET
3. Press the Omnipad at or to select
the menu item desired and press the
[ENT] key. For example select RESET.
DISTANCE RUN DISPLAY
DATA DISPLAY
CONTACT CLOSURE
RESET OFF
SET
OFF
ON
4. Press the Omnipad at or to select
the menu option desired and press the
[ENT] key.
5. Press the [MENU] key twice to close the
menu. (Some menus require only a
single pressing of the [MENU] key.)
To enter numerical data
Some menus require input of numeric data.
This is done with the Omnipad.
1. Select the digit or sign (+ or -) to change
with or on the Omnipad. (The
cursor shows the digit or sign selected.)
2. Enter a figure at each digit by hitting the
Omnipad at or . The example
below shows the DISTANCE RUN
DISPLAY menu, where you may adjust
the distance run indication for SET.
DISTANCE RUN DISPLAY
DATA DISPLAY
CONTACT CLOSURE
RESET OFF
SET
000000.00nm
ENT SET
Cursor
3. Press the [ENT] key to conclude.
1.6 Distance Run Operation
The operator may adjust and reset the
distance run indication and select display
method.
1.6.1 Selecting display method
The default setting provides for independent
display and adjustment of the distance run
indication on all displays (display unit,
Digital Indicator, distance indicator).
To show the same distance run indication
on all displays do the following:
1. Press the [MENU] key to open the
menu.
