6
1.3 Adjusting Contrast, Panel
Dimmer
1.3.1 Contrast
1. Press the [*] key to open the contrast
adjustment dialog box.
CONTRAST (0~63)
EXIT: [ENT]
41
2. Press the Omnipad at or to adjust
the contrast. The setting range is 0 to 63
and the default setting is 48.
3. Press the [ENT] key.
Note: The contrast is automatically set to
default (48) when the power is turned on.
1.3.2 Panel dimmer
1. Press the [DIM] key to show the dimmer
adjustment dialog box.
DIMMER (1~8)
EXIT: [ENT]
7
2. Press the Omnipad at or to adjust
the dimmer. The setting range is 1 to 8
and the default setting is 4.
3. Press the [ENT] key to conclude.
Note: The [DIM] key is inoperative when
dimmer is controlled externally.
1.4 Selecting a Display
Press the [DISP] key to select display
desired. Each time the key is pressed the
display shows speed and distance run or
speed alone as below.
[DISP] key
to switch
SPEED STW
DISTANCE
nm
10.0
12.50
SPEED STW
Speed
Distance
Run
kt
1 0 . 0
Direction
: Fore
: Aft
kt
•
Arrow indicates direction: indicates
fore; , aft.
•
The distance run indication shows the
total distance run in forward speed only.
•
The distance run is backed up when the
power is turned off.
Note: Speed error may occur in rough seas
because of air bubbles, etc.
When speed error occurs, the speed
indication freezes, and “KT” is highlighted
and blinks. If speed error continues more
than 30 seconds, the speed indication
changes to **.*.
