Furuno DS-80 - Manual (Page 35)

27
Model DS-80
Unit TRANSCEIVER DS-810
ELECTRICAL PARTS LIST Ref.Dwg. C7247-K02-A
2000-01 Block.No.
SYMBOL TYPE CODE No. REMARKS SHIPPABLE
ASSEMBLY
PRINTED CIRCUIT BOARD
65P6020,KCP
002-889-570 X
POWER SUPPLY ASSEMBLY
DS-810
002-889-530 X
SWITCH
S1 S-331 000-474-214
VARISTOR
CR1 ERZV-20D471 000-136-287
TRANSFORMER
T1 65S1218 000-142-647
TERMINAL BOARD
TB101 F1003-20A-5725-6P 000-137-321
NOISE FILTER
XF1 ZGB2202-01U 000-132-968
CABLE w/CONNECTOR
66-045(2P)
002-889-550 VH CONNECTOR
65-046(6P) 002-889-560 VH CONNECTOR
