C141-E078-02EN 3 - 3
Table 3.1 Zone layout and track capacity (MAF3364FC)
Zone 0 1 2 3 4 5 6
Cylinder 0 to 899 900 to
1,999
2,000 to
3,019
3,020 to
3,729
3,730 to
4,029
4,030 to
4,669
4,670 to
5,189
Byte/track 267,428 267,428 267,428 260,017 256,665 249,755 244,019
Sector/track 420 420 420 405 400 390 380
Zone 7 8 9 10 11 12 13
Cylinder 5,190 to
5,459
5,460 to
6,459
6,460 to
7,369
7,370 to
7,929
7,930 to
8,399
8,400 to
9,519
9,520 to
10,199
Byte/track 240,931 229,596 218,471 211,617 205,757 191,178 181,401
Sector/track 376 360 340 330 320 300 281
Remarks: The sector/track capacities are expressed in values when the logical data block is 512 bytes
long.
Table 3.2 Zone layout and track capacity (MAG series)
Zone 0 1 2 3 4 5 6
Cylinder 0 to 679 680 to
1,559
1,560 to
2,409
2,410 to
3,139
3,140 to
3,469
3,470 to
4,119
4,120 to
4,659
Byte/track 267,428 267,428 267,428 260,410 256,969 250,231 244,449
Sector/track 420 420 420 405 400 390 381
Zone 7 8 9 10 11 12 13
Cylinder 4,660 to
4,939
4,940 to
5,989
5,990 to
6,919
6,920 to
7,499
7,500 to
7,979
7,980 to
9,149
9,150 to
9,865
Byte/track 241,779 229,631 218,894 211,976 206,169 191,474 176,273
Sector/track 377 360 340 330 320 300 273
Remarks: The sector/track capacities are expressed in values when the logical data block is 512 bytes
long.
(1) User space
The user space is a storage area for user data. The data format on the user space (the length of
data block and the number of data blocks) can be specified with the MODE SELECT or MODE
SELECT EXTENDED command.
