fi-4220C2 Image Scanner Operator’s Guide 57
Chapter 4
REPLACING CONSUMABLES
This chapter describes how to replace scanner consumables.
In this chapter Windows XP screenshots are illustrated.
The screens and operations may differ slightly if the OS that you are using is other than Windows
XP.
Also, when FUJITSU TWAIN32 or FUJITSU ISIS is updated the screens and operations noted in
this chapter will differ slightly.
WARNING
When operating the scanner, the ADF’s inside glass becomes very hot.
Before you replace the consumables, turn off its power and unplug the AC adapter from the
outlet. Wait for at least 15 minutes.
4.1 Consumable and Replacement Cycle ............................................................ 58
4.2 Replacing the Pad Assy................................................................................... 63
4.3 Replacing the Pick Roller ................................................................................ 66
