2.9 Detecting Multi feeds
fi-4220C2 Image Scanner Operator’s Guide 45
SCANNING VARIOUS TYPES OF DOCUMENTS
2
The following detection conditions are provided:
None : Multi feed detection is not performed.
Check thickness : The scanner monitors the thickness of documents. It detects a multi
feed by differences in document thickness when two or more docu-
ment sheets are fed overlapping.
Check length : The scanner monitors the length of documents. It detects a multi
feed by changes in the document length when two or more document
sheets are fed overlapping.
Check thickness and length:
The scanner monitors both document thickness and length to detect
multi feed.
Furthermore, see "6.5 Multi feed Detection Conditions" (page. 99) for detailed information
about the document for multi feed detection.
4. Click the [OK] button.
The display returns to the [TWAIN Driver] dialog box. Continue scanning from this dialog
box.
