5.2 Remedying Typical Troubles
fi-4220C2 Image Scanner Operator’s Guide
85
TROUBLESHO
OTING
5
*1) For details on requirements, see "6.2 Document Quality" (page. 95).
*2) For details on multi feed, see "6.5 Multi feed Detection Conditions" (page. 99).
*3) For details on requirements, see "6.3 Maximum Document Loading Capacity"
*4) For details on how to clean the consumables, see "3.3 Cleaning the ADF" (page.
53).
*5) For details on how to replace and attach consumables, see "4 REPLACING CON-
YES
Clean the dirty consumables.
(*4)
Is any of consumables
(Pick roller and Pad Unit) dirty?
Is any of consumables (Pick roller
and Pad Unit) worn out? (Check
the consumable counter)
YES
Replace the consumable,
if needed. (*5)
NO
Are all the consumables
(Pick roller and Pad Unit) installed
correctly?
NO
Correctly install the
consumables if needed.
NO
YES
Continued from previous page
If you cannot solve the problem
after taking measures, check the
items in "5.3 Items to check before
contacting the dealer where you
bought the scanner" and contact
the dealer or an authorized
FUJITSU service provider.
