5.2 Remedying Typical Troubles
fi-4220C2 Image Scanner Operator’s Guide 87
TROUBLESHO
OTING
5
*1) For details on requirements, see "6.2 Document Quality" (page. 95).
*2) For details on how to clean the ADF, see "3.3 Cleaning the ADF" (page. 53).
*3) For details on how to attach the consumables, see "4 REPLACING CONSUM-
ABLES" (page. 57).
Use the document that
satisfy the requirements. (*1)
NO
YES
Is there any debris in the ADF?
YES
Clean the ADF or remove
debris from the ADF. (*2)
NO
Correctly install the
consumables (Pick roller and
Pad Unit), if needed. (*3)
YES
NO
Symptom 11 Paper jams occur frequently
Do the documents satisfy the
conditions described in
"6.2 Document Quality"?
Are all the consumables
(Pick roller and Pad Unit)
installed correctly?
Is any of consumables
(Pick roller, Pad Unit) dirty?
YES
Clean the dirty consumable.
(*2)
Is any of consumables (Pick roller
and Pad Unit) worn out? (Check
the consumable counter)
Replace the consumable,
if needed. (*3)
NO
YES
NO
If you cannot solve the problem
after taking measures, check the
items in "5.3 Items to check before
contacting the dealer where you
bought the scanner" and contact
the dealer or an authorized
FUJITSU service provider.
