Instruction Manual
D500243X012
1035/El-O-Matic Actuator
August 2012
3
Table 2. Performance Characteristics
E SERIES
ACTUATOR
SIZE
BORE
STROKE
AVERAGE
STROKE
TIME
(SEC)
(1)
FREE AIR VOLUME
(2)
FREE AIR
VOLUME
(2)
mm
Inch
mm
Inch
Port
“A”(liter)
Port
“A”(in
3
)
Port
“B”(liter)
Port
“B”(in
3
)
E25
56
2.2
15.7
0.62
0.5
0.1
6.1
0.11
6.7
E40
70
2.8
18.8
0.74
0.7
0.16
9.8
0.22
13.4
E85
80
3.1
22.0
0.87
1.1
0.33
20.1
0.36
22.0
E100
91
3.6
25.1
0.99
1.2
0.35
21.4
0.49
29.9
E200
110
4.3
37.7
1.48
2.2
0.8
48.8
1.0
61.0
E350
145
5.7
37.7
1.48
3.7
1.8
110
1.9
116
E600
175
6.9
44.0
1.73
3.3
2.9
177
3.1
189
E950
200
7.9
50.3
1.98
5.4
4.7
287
4.9
299
E1600
230
9.1
62.8
2.47
5.8
7.3
445
8.0
488
P2500/P2505
300
11.8
56.5
2.22
6.7
8.0
488
9.3
567
P4000/P4005
325
12.8
81.7
3.22
12.4
13.5
824
17.5
1068
1. These times assume smaller solenoids for smaller actuators and larger solenoids for larger actuators with varying Cvs, but a constant air supply pressure of 80 psi (5.51 bar). E25 to E350
assume a 0.09 Cv (0.08 Kv); E600 & E9500 a 0.26 Cv (0.22 Kv); E1600, P2505 & P4005 a 0.51 Cv (0.44 Kv).
2. To calculate air consumption per stroke multiply free air volume X air supply pressure (absolute).
Figure 2. Typical Actuator Assembly
SPRING
STANDARD SQUARE END
STANDARD SQUARE
DOUBLE D CONNECTION
COUPLER
DOUBLE ACTING
ACTUATOR
E SERIES INSERT
END CAP SPRING RETURN
W6954
