Fisherr POSI-SEAL™ 1035/El-O-Matic
Rack-and-Pinion Rotary Actuator
Contents
Introduction 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scope of Manual 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Description 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjustment 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Actuator Disassembly 13 . . . . . . . . . . . . . . . . . . . . . . .
Actuator Assembly 16 . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing Rotation Direction 18 . . . . . . . . . . . . . .
Spring Return E Series Actuators 20 . . . . . . . . . . .
Spring Return P Series Actuators 20 . . . . . . . . . . .
Installing the Bypass Valve 20 . . . . . . . . . . . . . . . .
Parts Ordering 21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts Kits 22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts List 23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 1. Fisher POSI-SEAL 1035/El-O-Matic Actuator
with A41 Valve
W9255
Introduction
Scope of Manual
This instruction manual includes installation, maintenance, and parts ordering information for Fisher POSI-SEAL
1035/El-O-Matic rack-and-pinion rotary actuators (figure 1). These actuators are available in both double-acting and
spring-return (figure 2) configurations. Spring return units provide fail action in response to spring compression. The
actuator is field reversible. Instructions for the valve and for any accessories used with the actuator are found in
separate manuals.
Do not install, operate, or maintain a 1035 actuator without being fully trained and qualified in valve, actuator, and
accessory installation, operation, and maintenance. To avoid personal injury or property damage, it is important to
carefully read, understand, and follow all the contents of this manual, including all safety cautions and warnings. If you
have any questions about these instructions, contact your Emerson Process Management sales office before
proceeding.
Instruction Manual
D500243X012
1035/El-O-Matic Actuator
August 2012
