Parts reference, Instruction manual, 1035/el-o-matic actuator – Fisher D500243X012 User Manual
Page 23: Table 7. e series parts list
Instruction Manual
D500243X012
1035/El-O-Matic Actuator
August 2012
23
Parts Reference
Table 7. E Series Parts List
Key Number
Description
Quantity
1
Body, If you need an actuator body (key 1) as a replacement part , order by
actuator size, serial number, and desired material. Contact your Emerson sales
office.
1
2
Piston, Aluminum alloy
2
3
Drive shaft, Aluminum
1
4
End cap (EDN), Aluminum alloy
2
5
End cap (ESN), Aluminum alloy
2
6
Spring - inner, Steel
2
7
Spring - mid, Steel
2
8
Spring - outer, Steel
2
9
Spring holder, Steel
2
10*
Guide band, Nylon
1
11*
Guide band, PTFE carbon filled
2
12*
Bearing Bushing Bottom, Nylon
1
20*
Top bearing bushing, POM
(1)
1
21*
Trust washer, POM
(1)
1
22*
Washer, PTF
1
23*
Washer, PTF
1
22*
Body O-ring, Nitrile
2
23*
Piston O-ring, Nitrile
2
25*
End cap O-ring, Nitrile
1
26*
Shaft Bottom O-ring, Nitrile
1
27*
Washer, PTFE
1
28*
O-ring, Nitrile
1
29*
End cap O-ring, Nitrile
2
30*
End cap O-ring, Nitrile
2
34
Washer, steel
2
35*
Spring clip
1
36
Socket Head Cap Screw, Steel
8
37
Travel Stop Screw (ESN), Steel
2
38
Hex nut, Steel
2
39
Nut cover, Polyethylene
2
40
Travel stop screw (EDN), Screw
2
41
Hex nut, steel
2
42
Nut cover, polyethylene
2
43*
O-ring, Nitrile
2
44
Insert
1
- - -
Housing adjustment screw, steel
(figure 4)
1
- - -
Stroking adjustment cam, steel
(figure 4)
1
- - -
Hex (lock) nut, steel (figure 4)
1
- - -
Hex (lock) nut, polyethylene (figure 4)
1
- - -
Lubricant, Standard and High Temperature Construction
CCSG
(2)
- - -
Lubricant, Low Temperature Construction
Low Temperature Silicone Grease
1M5964X0012
* Recommended spare parts (contained in a repair kit).
1. Polyoxymethylene.
2. Complex Calcium Sulphonate Grease.
