51
TECHNICAL DATA
Magnification 8x 10x
Lens diameter 42mm
Exit pupil 5.2mm / 13 /
64
" 4.2mm / 11 /
64
"
Twilight number 18.3 20.5
Geometric luminous intensity 27.5 17.6
Field of vision (at 1,000m) /
Objective field of view
Approx.128m /142yds / 7.3° Approx. 113m /125yds / 6.5°
Exit pupil longitudinal distance 18mm / 45/64“ 16mm / 25/32“
Close range limit Approx. 5m/yds
prism type Perger prism
Coating on lenses and prisms High Durable Coating (HDC™) and hydrophobic Aqua-Dura coating on external lenses, P40 phase correction coating
Diopter compensation ±4dpt.
Eyepiece cups Adjustable by turning for use wearing glasses, 4 settings, removable for easy cleaning
Eye spacing Adjustable, 56 – 74mm/ 27/32“ – 229/32“
Operating temperature Electrical system: -20°C/-4°F to 55°C/131°F, mechanical system: -30/-22°F to 55°C/131°F
Storage temperature -40 to 85°C / -40 to 185°F
Water tightness Impermeable to press water up to 5m/yds deep
Housing / chassis material Die cast magnesium, non-slip rubber reinforcement
Range Approx. 10m/yds - 1825m/2000yds
Measuring accuracy Approx. ±1m/y up to 500m/yds / Approx. ± 2m/yds up to 1000m/yds / Approx. ± 0.5% over 1000m/1000yds
Display/Unit of measure 4-digit LED/optionally in yards/inches or meters/centimeters
Battery 3V lithium button cell, CR2 type
Battery life Approx. 2,000 measurements at 20°C/68°F
Laser Invisible, safe for eyes in compliance with EN and FDA Class 1
Laser beam divergence Approx. 0.5 x 2mrad
Maximum measurement
duration
Approx. 0.9s
Dimensions (W x H x D) Approx. 127 x 81 x 177mm /
Weight (with battery) Approx. 950g
