46
DISpLAYING AND CHECKING THE SET
BALLISTICS pARAMETERS
If you want to check your settings, you can display the
values at any time.
To do this, briefly press the secondary / menu button
(8) twice.
•
The following information briefly appears in turn
below the reticule (instead of the range) for approx.
2s:
– The set ballistics curve (see p. 41)
– The set zeroing distance (see p. 42)
– The set ballistic output value (see p. 45)
If all ballistics functions are deactivated (
bALL
= OFF),
only the
US
or
EU
setting is displayed.
USING ALTERNATIVE BALLISTICS CURVES
If the intended weapon / ammunition combination is
not covered by one of the 2 x 12 programmed
ballistics curves on the Leica Geovid HD-B you can
use your own custom ballistics curves. These are
initially precisely calculated based on the load data
your provide online - such as caliber, ammunition
weight etc. - and then transferred to the microSD
memory card supplied so that it can be retrieved on
the binoculars once the card has been inserted.
This is done in three stages:
A. Calculation and transfer of requested ballistics
curve to the memory card.
On the Leica Camera AG homepage at www.
leica-camera.com, the Sport Optics area
– includes instructions for entering the required
information/values for calculation of a ballistics
curve
– the corresponding input screen
– a description of the download process,i.e. how to
transfer the calculated ballistics curve to the
memory card
