pOINT OF IMpACT CORRECTION USING

ELEVATION ADJUSTMENT (CLICK / MOA

ADJUSTMENT)

Variations in the point of impact can be compensated

by a corresponding adjustment of the reticule on your

telescopic sight.

Taking into account the measured range, the

trajectory of the bullet and the set zeroing distance

(see p. 42), the Leica Geovid HD-B can display the

required adjustments, i.e. the relevant number of

clicks.

For the different elevations, you can specify whether

the clicks are to be specified

– based on the international standard MOA (minutes

of angle) graduation, or

– in 5 or 10 centimeter graduations.

SETTINGS AND SELECTION OF BALLISTIC

OUTpUT FORMATS

Start with step 1 if you have not yet opened the menu

system and with step 3 if you have already set the unit

of measure and

ABC

is still flashing in the display.

1. Press and hold (≥2s) the secondary / menu button

(8).

•

US.EU

appears.

2. Briefly (<2s) press the secondary / menu button

three times.

•

The display changes to

bALL

and

SId

and then to

ABC

3. Select the relevant ballistic setting by repeatedly

pressing the main / release button (7).

–

EHr

–

HOLd

–

1-1

(1MOA), or

–

1-3

(1/3MOA), or

–

1-4

(¼MOA), or

–

4. Save your setting by pressing the secondary /

menu button.

•

The saved setting is displayed continuously for

4s as confirmation and the display then goes out.
