Page- Changes display to next page. If there are more levels than show in LCD display,
Page will display next set of levels.
Dest Lock- Locks current destination from changing to another source.
Salvo Menu- The “Salvo Menu” function will display the list of Salvos in the LCD of the
panel for selection.
Salvo-
Selecting “Salvo” allows you to select a specific salvo from the Function
Params list.
Select All Levels- Enables all levels Note; all levels are enabled as a default. This
function restores all levels to enable if the previous switch was other than all levels.
Clear Dest- Clears destination entry and places the cursor in the destination field.
Clear Source- Clears source entry and places the cursor in the source field.
Name vs Number- Toggles between Alpha and Numeric sort.
Panel Options
Single Destination Only- Any control panel can be a single destination panel if desired.
If the panel is to be a “Single Bus” (only controls 1 output), place a check in the “Single
Destination Only” box. Placing a check in the “Single Bus” box will cause the panel to
only access and switch the single selected output.
If there is no check in the box and only one output is selected for the panel to control, the
panel can status the blocked outputs but only switch the selected output.
Show UnMapped Levels- Levels that are unmapped will be displayed in status.
Unchecked will hide unmapped levels.
Enable Auto Take- If this box is checked, router will “Take” when source is selected. Un-
checked will require a “Take” button to be pressed to initiate switch.
Enable Numeric Sort- If this box is checked, inputs and outputs will be sorted by number
rather than by name. Sorting by name is alphabetic.
Display Brightness- Changes the brightness of the LCD display.
Select Holddown Mode- There are 3 choices of the “Holddown” mode.
When level button is held down for 3 seconds it will cycle through a series of enabled and
disabled. In the 2-Way Cycle mode, holding down the level button toggles between all on
to only the selected on. 3-Way Cycle Mode, holding down the level button toggles
between selected on, all on, and selected off others on. Disable toggles the level on or
off.
