8.50 in
4.25 in
1.75 in
Figure: 3
Figure 3 shows the location of the front slit to cut, the dimension shown is from top of the
hump. The 8.50 in dimension is centered as shown by the 4.25 in dimension and in figures 1 & 2.
Dimensions For Locating Cut Pattern
Page 17 of 21
