7
Keypad
Number KEYPAD Numeric 1 to 6 digits.
This is the number entered by an employee at a reader. Also known as
the PIN (personal Identification Number). A keypad number must be
assigned if the employee is to use a keypad reader.
Record Last
Updated LASTUPDT Numeric
(Date) This is the computer generated date for the last time the record was
updated. This field must be left blank so that the computer generates
the information based on the date the file is uploaded into the host
system.
Cardholder
flags ONLFLAGS Numeric 0-255 
For import, add the following values together:
• if authorized for guard tour (Sapphire Pro only), add 1,
• if authorized to bypass anti-passback (GUI field Executive APB
override), add 2,
• if a visitor card (Sapphire Pro only), add 4,
• if cardholder access should be traced, add 8
Affiliation
flags ONLAFLAG Numeric 0 - 9
• For Topaz, always 1 (employee)
• For Sapphire Pro, 1 for employee, 9 for visitor
Tenant ID OPGRPID Numeric ID of operator group
Photo ID
Number PHOTOID Numeric This is the name of the photo of the Cardholder. The photo file itself
must be in the BADGER folder on the Server. The photo must have a
special indexed numerical name. See Section 2 for details
Emergency
Contact
Relationship RELATION Alphanumeric Up to 16 characters.
This is a reference field that may be used at the option of the system
owner.
Security Area ---- Header is
ASCII
Value is
Numeric Up to 12 characters.
To add a Security Area to a record, use the ASCII name of the Security
Area as the Field Header. Then enter the Time Schedule ID Number as
the Field Value. If the record is NOT to have the security area, enter a
Field Value of zero (0)
Security area 1 SA Numeric ID of first authorized Security
Security area 1 SA1 TZ Numeric ID of time schedule when access is authorized to corresponding
security area.
Security area 1 SA 2 Numeric ID of second authorized Security
Security area 1 SA 2 TZ Numeric ID of time schedule when access is authorized to corresponding
security area.
Security area 1 SA 3 Numeric ID of third authorized Security.
Security area 1 SA 3 TZ Numeric ID of time schedule when access is authorized to corresponding
security area.
Security area 1 SA 4 Numeric ID of fourth authorized Security
Functional
Field Name Protocol
Field Name
Type of Value Description
