Configuration Guidelines:
Next are the basic operation guidelines on how to set SATA devices including optical reader, writers, and/or hard
drive. The system will automatically detect the drives and assign drive numbers.
READER WRITER
Hard Disk
Drive (HDD)
System Setting Information
1 Installed Installed No
When machine is turned on, the system will detect and assign the
READER drive as the Source Drive, which will be automatically
set as Drive #1. WRITERS will be set as Writer Drives and
assigned in sequential order after the READER drive, starting
from Drive#2, Drive#3, etc.
2 No Installed No
When machine is turned on, the system will assign the WRITER
drive connected to Port#1 of the controller as the Source Drive
and as Drive#1. The rest of the WRITERS will then be set as
Writer Drives and numbered in sequential order beginning from
Drive#2 and on.
3 No Installed Installed
When machine is turned on, the system will assign the
Hard Disk Drive (HDD) as the Source Drive
and as Drive#1. The WRITERS will then be set as
Writer Drives, and numbered in sequential order beginning from
Drive#2 and on.
4 Installed Installed Installed
When all drives are installed, Port #1 will be connected to Hard
Disk Drive (HDD), Port #2 will be connected to the Source
drive. WRITERS will be set as Writer Drives and numbered in
sequential order from Drive#3 and on.
Menu Overview (Expert Mode):
Below is a quick reference chart of the functions available on this DVD/CD Duplicator Controller. After the
drives are successfully installed, user may access the menu functions by powering on the system.
1 COPY Copies the master DVD/CD. All contents of the master disc will be duplicated on
to all target disc(s) simultaneously.
2
TEST Simulates the copy process, but no data is recorded onto the blank disc(s).
Note: Test mode can only be done with DVD-R and CD-R media only.
3 COPY + VERIFY Copies the master DVD/CD, and then verifies the presence of data on the
copied disc(s) to ensure readability of the copied disc(s).
4 COPY + COMPARE Copies the master DVD/CD, and then immediately follows the copy process
with a bit-for-bit comparison between the master disc and copied disc(s) to
ensure exact duplication.
Note: The “Compare” function cannot be used with audio CDs.
5 VERIFY Verifies the presence of data on the copied disc(s) to ensure that the copied
disc(s) can be read back.
6 COMPARE Performs a bit-for-bit comparison between the master disc and copied disc(s).
7 SET BURN SPEED Allows the speed settings to be changed for various formats.
8 SOURCE SELECT Allows the source drive to be changed to any of the available drives in the
duplicator, including the Hard Disk Drive (HDD).
