QTS MATERIALS EVALUATION SYSTEM OPERATOR MANUAL
Page 7
4.3 Hardware
a) The probe assembly (1) revolves freely. Probes may be screwed on by holding the
probe assembly between the thumb and forefingers with one hand and the probe in
the other. Alternatively, a small key is provided which may be inserted in the hole in
the probe assembly to prevent it from turning whilst loading or unloading a probe.
a) The working surface of the straining frame has a T shaped slot, which is used to
attach fixtures.
b) The loadcell has an M6 connection, which is used for attaching the top part of
fixtures (where appropriate)
c) Probes have an M3 connection, and are attached to the loadcell using any of the
three adapters supplied with the instrument.
d) At the front of the straining frame there are six LED's (Light Emitting Diodes) which
indicate the current status of the instrument. Refer to Figure 3.
e) The emergency stop button is located on the left-hand side of the front of the
instrument.
• To operate the emergency stop depress the button. This will stop the beam
from travelling.
• To release an emergency stop status twist the emergency stop button
clockwise until it springs out, then press the 'ABORT' key on the QTS
Controller. The beam will return to its original position when the 'ABORT'
KEY IS PRESSED.
4.4 Programming a Test Method
Note: The QTS Controller has a memory capable of storing 100 test methods, numbered
00 to 99.
a) Press 'PROGRAM' and using either the up and down ↑↓ keys or the numerical
keypad select a number between 00 and 99.
Press 'ENTER'.
b) The display now reads:
< Defining test 20 >
< SINGLE, HOLD, CYCLE, REPEAT/TPA >
The test type should be chosen using the up and down ↑↓ keys to scroll between
Single, Hold, Cycle, and Repeat/T.P.A.
Press 'ENTER'
• A SINGLE test is a one-cycle test where the beam travels to the target value
at test speed and then immediately returns to the starting position at full speed.
