Brookfield QTS25 Texture Analyzer User Manual
Page 17
QTS MATERIALS EVALUATION SYSTEM OPERATOR MANUAL
Page 17
5. OUTPUT CONNECTIONS
The output connection are located at the rear of the instrument and are shown in Figure 2.
(a) This is the mains connector.
(b) This is a DIN connector for use with a Chart Recorder.
(c) This is the QTS Controller keypad connector.
(d) This is an RS232 connector for linking to a P.C.
(e) This is a printer port.
