QTS MATERIALS EVALUATION SYSTEM OPERATOR MANUAL
Page 16
Select utility: < .. Erase test ... >
Press 'ENTER' Erase test no :
**: "description"
Key in Test No. to be erased e.g. 12
12: "description"
Press 'ENTER'
The test will now have been erased.
g) < .. Status and Log .. >
Ensure printer is connected, on-line and the 'Print' LED is lit on the Controller
Keypad.
Note: If in CONFIGURE mode the 'Print' LED cannot be lit. To activate press 'Abort'
then 'Print' then 'Configure'.
Select utility: < .. Status & Log .. >
Status report
in print queue
The printer will print a QTS status report of 8 internal flags plus Programmed
Stores (which are the current programmes stored in memory).
This function can only operate with a printer.
