I. APPENDIX
MAXIMUM RECOMMENDED CAPACITIES
Model
EY7541
Screw driving
Wood screw
03.5-09.5 mm (1/8"-3/8")
Seif-drilling screw
03.5 - 06 mm (1/8" -1/4")
Bolt fastening
Standard bolt : M6 - M16
High tensile bolt : M5 - M12
I. SPECIFICATIONS
MAIN UNIT
Model
EY7541
Motor
14.4 V DC
No load speed
soft mode
0 -1000 /min (rpm)
medium mode
0 -1400 /min (rpm)
hard mode
0 - 2300 /min (rpm)
Maximum torque
165 N m (1680 kgf-cm,l460in-lbs.)
Impact per minute
soft mode
0 - 2000/min (bpm)
medium mode
0 - 2800 /min (bpm)
hard mode
0 - 3000 /min (bpm)
Overail length
158 mm (6-1/4")
Weight (with battery pack : EY9L40)
1.45 kg (3.1 lbs)
BATTERY PACK
Model
EY9L40
Storage battery
Li-ion Battery
Battery voltage
14.4 V DC (3.6 Vx 4 cells)
BATTERY CHARGER
Model
EY0L80
Rating
See the rating plate on the bottom of the charger.
Weight
0.95 kg (2.1 lbs)
- 13 -
