TSM_MITX_20140703_R1-00
Page 6 of 26
Table 2 lists the components identified in Figure 1
Table 2. Components Show in Figure 1
Item from Figure 1 Connector Description
A F_Audio Front panel audio header
B SIM_Card SIM Card socket
C JVGA VGA header
D Back Panel Connectors Back Panel Connectors
E ATX1 Internal power connector
F SATA_PW1 SATA power connector
G SATA_PW2 SATA power connector
H M-SATA mSATA full or half-mini card slot
I SATA2 SATA data connector
J CPU FAN 3-wire CPU fan header
K SYS FAN 3-wire system fan header
L CLR_CMOS Clear CMOS jumper
M LVDS LVDS connector
N LVDS-PWR_SEL Flat panel voltage selection jumper
O BLT_PWR Flat panel backlight power header
P MON_SW Momentary Switch header
Q BLT_PWR_SEL Flat panel backlight selection header
R F_PANEL Front panel header
S COM1, COM2 Serial port headers
T USB USB headers (on some configuration)
U TPM_Hearder Trusted Platform Module Header
V LPT Parallel port header
W USB USB headers
X KS/MS KS/MS
Y Mini-PCIE PCI Express Full/Half-Mini card slot
Z PCIE PCI Express 1.0a x1 connector
AA USB USB 3.0 header
BB INT_SPK Internal stereo speakers connector
CC SPDIF S/PDIF header
DD Factory use
