TSM_MITX_20140703_R1-00
Page 14 of 26
Table 17. Panel Switch header (Figure. 5. N)
Pin Signal Name
1 DISPLAY_ON/OFF
2 GND
Table 18. Flat panel backlight power selection header (Figure. 5. O)
Pin Description
1, 2 Close 12V
2, 3 Close VDC
Table 19. Front panel header (Figure. 5. P)
Pin Signal Name
1 HD_LED-
2 PWR_LED-
3 HD-LED+
4 PWR_LED+
5 RESET
6 Power Button
7 GND
8 GND
9 NC
10 Key
Table 20. Serial port headers (Figure. 5. Q)
Pin Signal Name
1 NDCD
2 MSIN
3 NSOUT
4 NDTR
5 GND
6 NDSR
7 NDSS
8 NCTS
9 NRI
10 N/A
Table 21. Parallel port header (Figure. 5. R)
Pin Signal Name Pin Signal Name
1 P_STB 2 P_AFD
3 P_D0 4 ERRJ
5 P_D1 6 P_INIT
7 P_D2 8 P_SLIN
9 P_D3 10 GND
11 P_D4 12 GND
