TSM_MITX_20140703_R1-00
Page 16 of 26
13 REFCLK+
14 Reserved
15 GND
16 Reserved
17 Reserved
18 GND
19 Reserved
20 Reserved
21 GND
22 PERST#
23 PERn0
24 +3.3 V aux
25 PERp0
26 GND
27 GND
28 +1.5 V
29 GND
30 SMB_CLK
31 PETn0
32 SMB_DATA
33 PETp0
34 GND
35 GND
36 USB_D-
37 GND (mSATA) GND
38 USB_D+
39 +3.3 V aux (mSATA) 3.3 V
40 GND
41 +3.3 V aux (mSATA) 3.3 V
42 LED_WWAN#
43 Reserved NC (mSATA indicator)
44 LED_WLAN#
45 Reserved (mSATA) Vendor
46 LED_WPAN#
47 Reserved (mSATA) Vendor
48 +1.5V
49 Reserved (mSATA) DA/DSS
50 GND
51 Reserved (mSATA) Presence Detection
52 +3.3 V aux
Table 26. USB 3.0 header (Figure. 5. W)
Pin Signal Name
1 USB_PWR
2 NC
