TSM_MITX_20140703_R1-00
Page 24 of 26
Item Field Description
USB OTG Support
PCI mode
Disabled Select Enabled USB OTG Port
support
USB VBUS
On
off Select Enabled USB VBUS
support
XHCI Mode
Enabled
Disabled
Auto
Smart Auto
Select USB XHCI Mode support
USB2 Link Power Management
Enabled
Disabled Select Enabled USB USB2 Link
Power Management support
USB 2.0(EHCI) Support
Enabled
Disabled Select Enabled USB 2.0 EHCI
support
USB Per Port Control
Enabled
Disabled Select Enabled USB per port
control
USB Port 0
Enabled
Disabled Select Enabled for USB Port 0
support
USB Port 1
Enabled
Disabled Select Enabled for USB Port 1
support
USB Port 2
Enabled
Disabled Select Enabled for USB Port 2
support
USB Port 3
Enabled
Disabled Select Enabled for USB Port 3
support
Restore AC Power Loss
Item Field Description
Restore AC Power Loss
Power off
Power on
Last State
Select Power-Off for
the system power to remain off
after a power loss. Select Power-
On for the system
power to be turned on after a
power loss. Select Last State to
allow the system
to resume its last power state
before a power loss.
Table 35. BIOS Setting - Security
Main Advanced Chipset Security Boot Save& Exit
Administrator Password
User Password
Table 36. BIOS Setting - Boot
Main Advanced Chipset Security Boot Save& Exit
Boot Option Priorities
Item
Field Description
Boot Option #1 UEFI: Built-in EFI Shell
Prioritize the order of bootable
devices that the system to boot
from
Table 37. BIOS Setting - Save & Exit
Main Advanced Chipset Security Boot Save & Exit
