TSM_MITX_20140703_R1-00
Page 20 of 26
Table 33-1. Advanced - Super IO Configuration
Main Advanced Chipset Security Boot Save& Exit
Super IO Configuration
Serial Port 1 Configuration
Item Field Description
Serial Port
Disabled
Enabled
Select Enabled to
enable the onboard
serial port
Change Settings
Auto
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h; IRO=3,4,5,6,7,9,10,11,12;
This feature specifies
the base I/O port
address and the
Interrupt Request
address of Serial Port
Serial Port 2 Configuration
Item Field Description
Serial Port
Disabled
Enabled
Select Enabled to
enable the onboard
serial port
Change Settings
Auto
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h; IRO=3,4,5,6,7,9,10,11,12;
This feature specifies
the base I/O port
address and the
Interrupt Request
address of Serial Port
Parallel Port Configuration
Item Field Description
Parallel Port
Disabled
Enabled
Select Enabled to
enable the onboard
Parallel port
Change Settings
Auto
IO=378h; IRQ=5; DMA=3;
IO=378h; IRQ=5,6,7,9,10,11,12;DMA=1,3;
IO=278h; IRQ=5,6,7,9,10,11,12;DMA=1,3;
IO=3BCh; IRQ=5,6,7,9,10,11,12;DMA=1,3; This feature specifies
the base I/O port
address and the
Interrupt Request
address of Parallel Port
Device Mode
Standard Parallet Port Mode (SPP)
EPP Mode
ECP Mode
EPP Mode & ECP Mode
Select the feature of
mode of the onboard
Parallel Port
Table 33-2. Advanced - Super IO Hardware Monitor
Main Advanced Chipset Security Boot Save& Exit
Super IO Hardware Monitor
PC Hardware Monitor Status
Item Field Description
Smart Fan Mode Full on Mode
Automatic Mode
Manual Mode Select how the system controls
the speeds of the
onboard fans
PWM slope setting 1 PWM
2 PWM Select the fans to run at x PWM
(Pulse Width Modulation) per
