TSM_MITX_20140703_R1-00
Page 11 of 26
Table 4 - 29 lists the connectors and headers identified in Figure 5.
Table 4. Front panel audio header (Figure. 5. A)
Pin Signal Name Description
1 MIC_L Front Panel MIC in Left
2 GND Ground
3 MIC_R Front Panel MIC in Right
4 N/A
5 FRONT_R Front Panel Audio out Right
6 F_IO_SENCE Front Audio Jack detection
7 GND Ground
8 N/A
9 FRONT_L Front Panel Audio out Left
10 F_IO_SENCE Front Audio Jack detection
Table 5. VGA header (Figure. 5. B)
Pin Signal Name
1 DAC_5V
2 5V_VSYNC
3 5V_HSYNC
4 GND
5 VGA_R
6 GND
7 VGA_G
8 GND
9 VGA_B
10 GND
11 VGA_DDC_DATA
12 VGA_DDC_CLK
Table 6. Internal power connector (Figure. 5. C)
Pin Signal Name
1 Power (12/19V DC)
2 GND
Table 7. SATA power connector 1 (Figure. 5. D)
Pin Signal Name
1 VVC_3V
2 VVC_3V
3 VVC_3V
4 GND
5 GND
6 GND
7 VVC_5V
