TSM_MITX_20140703_R1-00
Page 13 of 26
Table 13. Clear CMOS jumper (Figure. 5. J)
Pin Description
1, 2 Open Normal
1, 2 Close Clear CMOS
Table 14. LVDS connector (Figure. 5. K)
Pin Signal Name Pin Signal Name
1 LVDS_PWR 2 LVDS_PWR
3 LVDS_PWR 4 GND
5 GND 6 GND
7 LVDS_TX_A0N 8 LVDS_TX_A0P
9 LVDS_TX_A1N 10 LVDS_TX_A1P
11 LVDS_TX_A2N 12 LVDS_TX_A2P
13 GND 14 GND
15 LVDS_TX_CLKAN 16 LVDS_TX_CLKAP
17 LVDS_TX_A3N 18 LVDS_TX_A3P
19 LVDS_TX_B0N 20 LVDS_TX_B0P
21 LVDS_TX_B1N 22 LVDS_TX_B1P
23 LVDS_TX_B2N 24 LVDS_TX_B2P
25 GND 26 GND
27 LVDS_TX_CLKBN 28 LVDS_TX_CLKBP
29 LVDS_TX_B3N 30 LVDS_TX_B3P
Table 15. Flat panel LVDS voltage power jumper (Figure. 5. L)
Pin Description
1, 2 Close 12V
3. 4 Close 5V
4, 5 Close 3.3V
Table 16. Flat panel backlight power header (Figure. 5. M)
Pin Signal Name
1 LCD_BKLT_ON
2 BKLT_PWM
3 VIN_LVDS_F
4 VIN_LVDS_F
5 GND
6 GND
7 BLT_UP
8 BLT_DOWN
