4. I
NSTALLATION
W
HEATHEART
- S
ELF
-P
ROPELLED
P
OST
P
OUNDER
K
IT
4.7. H
YDRAULICS
T
RAILER
P
OST
P
OUNDER
M
ODEL
26
IM12 R3
4.7. HYDRAULICS
Note:
Hydraulic fittings must face in the direction shown in Figure 4.11.
Figure 4.11
Important:
Refer to the Hydraulics Parts for hydraulic hose routing.
FITTINGS
MUST FACE
IN THIS
DIRECTION
