Figure 4.1) – Wheatheart Self-Propelled Post Pounder Kit User Manual
Page 20

4. I
NSTALLATION
W
HEATHEART
- S
ELF
-P
ROPELLED
P
OST
P
OUNDER
K
IT
4.2. W
HEEL
D
RIVES
T
RAILER
P
OST
P
OUNDER
M
ODEL
20
IM12 R3
Figure 4.1
6. Reinstall
the
wheel hubs and wheels and engage the over-center handle
(Figure 4.2). Make sure that the pinion gear and ring gear mesh fully,
providing maximum tooth contact. Check also that the pinion clears the ring
gear when the handle is pulled up (disengaged).
Figure 4.2
1-1/4”
BETWEEN
BACKING
PLATE &
AXLE CAP
CHECK EDGE IS
VERTICAL USING
LEVEL
GUSSETS
AXLE CAP
ASSEMBLY
