3. O
PERATION
W
HEATHEART
- S
ELF
-P
ROPELLED
P
OST
P
OUNDER
K
IT
3.1. P
LACEMENT
& O
PERATION
P
ROCEDURE
T
RAILER
P
OST
P
OUNDER
M
ODEL
16
IM12 R3
6. When on a hill/slope, or if the machine moves ahead or back when pounding,
use the spike to secure the pounder in place (Figure 3.4). See Post Pounder
manual for details on operation.
Note:
When building a new fence, it is much easier to operate the machine in reverse
so you can look down the line while pounding the post. This ensures the line is
straight.
MOVE
CYLINDER
LOCK TO
SIDE OF
SPIKE FOR
OPERATION
Figure 3.2
SPIKE
Transport
Position
Operation
Position
LOCKING PIN
LOCKING PIN
HAIRPIN
HAIRPIN
Figure 3.3
WHEEL ARM
MOUNT
WHEEL ARM
MOUNT
CAUTION
Chock wheels or lower spike to prevent
machine from rolling and to improve stability.
WARNING
Run-Over Hazard! To prevent injury be
careful when backing up machine.
