4-5
Service Reference Manual COMPONENT LOCATION ILLUSTRATIONS
SRM-HW/HWC 2/99
HW/HWC Exterior Louver/Grill Panel
CONDENSER
AIR FLOW
OUTLET
EXTERIOR UPPER LOUVER PANEL
ARMSTRONG P/N 03545C000
EXTERIOR LOWER GRILL PANEL
ARMSTRONG P/N 03551D100
CONDENSER
AIR FLOW
INLET
SIDE VIEW
LOUVERS POINT UPWARD
AT 45° ANGLE
GRILL IS FLAT WITH
RECTANGULAR OPENINGS
FIGURE 4-4
Note: Panels found in the drawing above are not listed in the Parts List section that begins on page 8-1.
